Shrimad Gokul International Yellow three strand film rope is a strong, lightweight polypropylene rope that floats and has excellent resistance to oil, marine growth and most common chemicals. Lacks the abrasion resistance of standard monofilament polypro designed to not rot or deteriorate. Also available coil and wooden / plastic reel packing.
| DIAMETER | Yellow, Blue, Green, Orange, Red, White, Brown and other colours as per customer requirements |
|---|---|
| ROPE RANGE | 2 mm to 32 mm |
| COLOR | Yellow, white and other colors as per customer requirement. |
| TWIST RANGE | Single and double twisting both are available |
| TOLERANCE | +/-7% |
| COIL LENGTHS | 110 Mtr., 500 Mtr. and various lengths are available as per buyer requirement. |
| DIAMETER | CIR | WEIGHT | LINEAR DENSITY | MIN TENSILE | ||||
| 600′ | 183M | |||||||
| Inch | MM | Inches | lbs | kgs | Lbs/100′ | Kgs/100m | Lbs. | Kgs. |
| 3/16″ | 5 | 5/8″ | 3.6 | 1.63 | 0.6 | 0.89 | 808 | 367 |
| 1/4″ | 6 | 3/4″ | 6 | 2.72 | 1 | 1.49 | 1.249 | 567 |
| 5/16″ | 8 | 1″ | 9 | 4.09 | 1.5 | 2.23 | 1,899 | 862 |
| 3/8″ | 9 | 1-1/8″ | 13.5 | 6.13 | 2.25 | 3.35 | 2,698 | 1,225 |
| 7/16″ | 11 | 1-1/4″ | 20 | 9.08 | 3.33 | 4.96 | 3,498 | 1,588 |
| 1/2″ | 12 | 1-1/2″ | 24 | 10.9 | 4 | 5.95 | 4,196 | 1,905 |
| 9/16″ | 14 | 1-3/4″ | 36.62 | 16.63 | 6.1 | 9.09 | 5,066 | 2,300 |
| 5/8″ | 16 | 2” | 38.4 | 17.43 | 6.4 | 9.53 | 6,194 | 2,812 |
| 3/4″ | 18 | 2-1/4″ | 54 | 24.52 | 9 | 13.4 | 8,491 | 3,855 |
| 7/8″ | 22 | 2-3/4″ | 76.5 | 34.73 | 12.75 | 18.98 | 11,489 | 5,216 |
| 1″ | 24 | 3” | 90 | 40.86 | 15 | 22.33 | 13,987 | 6,350 |
| 1-1/8″ | 28 | 3-1/2″ | 116 | 52.66 | 19.33 | 28.78 | 18,282 | 8,300 |
| 1-1/4″ | 30 | 3-3/4″ | 138 | 62.65 | 23 | 34.24 | 20,982 | 9,526 |
